Laser Products LT-2D3D Laser Templator

For Sale Laser Products LT-2D3D Laser Templator. This unit excellent condition and fully tested. Come with warranty 90 days.

The LT-2D3D Laser Templator is a portable, 3D laser measuring system designed to help fabricators capture precise room and cabinet measurements. Built with an aircraft-grade aluminum chassis, it features a ±1/16” accuracy, up to 200-foot range, and weighs just 8 lbs.

Hardware Specifications

• • Measuring Range : Up to 200 feet (400-foot diameter)
  • Accuracy : ±1/16”
  • Weight : ~8 lbs. for the system
  • Battery : Extended-life rechargeable battery (up to 50-hour capacity)
  • Visibility : Full 360° virtual visibility for horizontal and vertical measurements
  • Construction : Aircraft-grade aluminum chassis with an impact-resistant polycarbonate housing

Software & Integration

• • Software : Proprietary, Windows-based
  • Output Formats : DXF, DWG, PDF, XML, and CSV
  • Tablet : Typically paired with a Microsoft Surface Pro tablet (12.3” touchscreen) for on-site drafting
  • Capabilities : Calculates square footage, linear footage, adds radii, offsets cabinet overhangs, and allows customers to digitally sign off on the job

Operational Efficiency

• • Setup Time : 5–10 minutes per room
  • Template Time : 20–30 minutes for a standard kitchen
  • Compatibility : Integrates directly with major industry platforms like Slabsmith and Moraware

Includes :

• • Heavy duty case
  • Tripod
  • Leather case for tripod
  • Tablet pro4
  • Hardware for countertop measuring
